The Regulating Oxygen Burner – ROX – was developed on basis of the Regulating Gas Burner for regenerative furnaces. The ROx enables the furnace operator to regulate the flame length and width of the flame for a superior melting performance. High degree flame coverage maximises the heat transfer to the glass at lowest NOx levels. This Burner have fully adjustable gas and oxygen nozzles. The gas ratio between the inner and the outer nozzle is adjusted by a control valve inside the burner. Control hand wheels at the back of the burner allowing a precise ratio control between the two gas velocities and the balance between gas and oxygen, ensuring a superior and fully flexible adjustment to production conditions and furnace geometries. Hotwork and UAS are specialised in supply of auxiliary equipment, including full gas control stations, furnace control system ( DCS ), full automation, exhaust gas analysis and Oxygen probes as well as tuning, supervision and commissioning services worldwide.
Gas Range: up to 950 Nm³/h
Gas Pressure: 200-500mBarg
Flame Length: up to 16m, depending on nozzle and adjustment
